Pressure

Nominal Range

10Kpa, 35kpa, 70kpa, 100kpa, 250kpa, 400kpa, 600kpa, 1Mpa, 1.6Mpa, 2.5Mpa, 4Mpa, 6Mpa 10Mpa, 16Mpa, 25Mpa

Pressure Reference

Gauge Pressure | Absolute Pressure| Sealed Gauge pressure

Overpressure

300%F.S.(70Kpa)|200%F.S.(＜25Mpa) |150%F.S(≥25Mpa)

Output Signal

Output

0.5 to 4.5V |4 to 20mA |1 to 5V |0 to 5V

Performance

Accuracy（including linearity, hysteresis and repeatability）

±0.5%F.S. (Typical)

Excitation

24VDC| 5VDC

Compensated Temp.

-20--80℃(typical)

Operating Temp.

-20-85℃

Storage Temp.

-40-85℃

Zero Temp. Coefficient

±0.03%F.S./℃

Span Temp. Coefficient

±0.03%F.S./℃

Pressure port

see last page ”how to order”

Housing material

Stainless steel 304 (SS316 for sensor inside)

Protection

IP65

Weight

95g(approx)

Electrical Connector

Round Packard

M12×1P

Cable outlet

Mini 4 pin

C1

C2

C3

C4

Current

（2 wire）

Voltage

（3 wire）

Current

（2 wire）

Voltage

（3 wire）

Current

（2 wire）

Voltage

(3 wire)

Current

（2 wire）

Voltage

(3 wire)

Pin 1 +Excitation

Pin2 +Output

Pin 3 Pending

Pin 1 +Excitation

Pin 2 –Excitation

Pin 3 +Output

Pin 1 +Excitation

Pin2 Pending

Pin 3 +Output

Pin 4 Pending

Pin1 +Excitation

Pin2  +Output

Pin 3 -Excitation

Pin 4 Pending

Red: +Excitation

Green: +Output

Red  +Excitation

Green –Excitation

Yellow  +Output

Pin1 +Excitation

Pin2 +Output

Pin 3 Pending

Pin1 +Excitation

Pin2 –Excitation

Pin 3 +Output

Pressure port

Thread

G1/4

1/4-18NPT

1/8-27NPT

Dimension in mm

Hex 24mm

Code

P1

P2

P3

Thread

M14×1.5

M12×1.5

1/4-19PT

7/16-20UNF(female)

Dimension in mm

Hex 24mm

Code

P4

P5

P6

P7
